Display:

Type: high resolution;

Size: 8 inches;

Sweep speed: 25 mm/sec.

Information: Heart rate; Lead / Electrode, Alarm ON / OFF, SpO2; Automatic defibrillation and prompt functions; Alarm and limit selection; Charge delivered.

Measurement range: 30~100%, ± 2% between 80% ~ 90%, others ± 5%;

Alarm range: selection between high or low limit;

Alarm accuracy: ±10% within the set values;

Alarm time accuracy: < 12 sec.

EtCO2 (Optional)

NIBP (Optional)

Waveform: biphasic;

Charge time: < 7 sec. with a new, fully charged battery;

Power: the display shows the selected and delivered power;

Prompt types: voice and visual;

Electrode impedance measurement range: 0 – 250 W.

Patient connection: ECG cable with three or five inputs via electrodes;

Lead selection: monitor display, pads, I, II, III, AVR, AVL, AVF, V; ECG sensitivity: 0.25, 0.5, 1, 1.5, 2, 4 mm / mV displayed on the monitor;

Heart rate: 20 – 300 BPM;

Heart rate alarm: ON / OFF displayed on the monitor;

Smart alarms: audible signal/voice commands indicate shockable arrhythmia.

Paper: 50 mm thermal paper;

Speed: 12.5 mm/sec, 25 mm/sec, 50 mm/sec; option to select 6 sec delay;

Printing method: high-resolution thermal print head;

Printing modes: manual or automatic, with adjustable settings;

ON / OFF control: front panel and electrodes.

Automatic function: 9-second recording, triggered by alarm activation, defibrillation charge, or defibrillation shock.

Automatic function: automatic analysis and charge x3 with pre-programmed automatic charge selection, on-screen commands, voice commands;

Automatic diagnosis of shockable arrhythmia: ventricular fibrillation with amplitude ≥ 200 mV, ventricular tachycardia with rate ≥ 400 bpm, QRS complex wave amplitude ≥ 140 ms;

Charge control: from the front panel; press the handle button;

Commands: visual and voice.

Type: rechargeable Ni-MH, 12V;

Operating time: for a new, fully charged battery – 60 defibrillation shocks at maximum charge, or a minimum of three hours of continuous ECG monitoring. Additional parameters affect operating time in different modes.

Charge selection at: 2, 5, 7, 10, 20, 30, 50, 70, 100, 150, 200, 300, 360 J;

Synchronized mode: synchronization of the defibrillation impulse with the patient's R-wave; the display shows the message "SYNC".
